Stainless Steel SS301/SS304 Rotary Joint Siphon Elbow For Paper Mill Dryer
  • name
  • name
  • name
  • name

Stainless Steel SS301/SS304 Rotary Joint Siphon Elbow For Paper Mill Dryer

Brand Name: FLRS or OEM
Model Number: FP-033
MOQ: 1 piece
Packaging Details: carton/ plywood cases/plywood pallets
Payment Terms: T/T， L/C， Western union， paypal
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO9001
Material:
Stainless Steel
Standard:
Standard
Connection Type:
THREADED
Application:
Drying Cylinders
Supply Ability:
100tons/month
Highlight:

Stainless Steel Rotary Joint Siphon Elbow

,

SS301/SS304 Rotary Joint Siphon Elbow

Product Description

Stainless Steel SS301/SS304 Rotary Joint Siphon Elbow For Paper Mill Dryer

The siphon elbow is specially designed for low-speed (≤80rpm) drying cylinders. It is used as a siphon device to discharge condensate after the steam is heated to release heat. This structure adopts hinge connection, which is convenient to install and easy to maintain. The two elbow joints are sealed with a refined ball head and the inner hole line connected to it. Relying on the weight of the siphon tube, it is easy to form a good static seal and sealing effect. Well, relying on the pressure difference between the siphon pipe and the steam inlet of the rotary joint, it is easy to realize the siphon and achieve a good drainage purpose.

PIPE FITTINGS
Product Name

 Siphon Elbow
Packaging: Plywood Cases or per customer’ s requirement
Quality High Level
Advantage
Easily installed
Leak tight sealing
Painting Anti-rust painting/ Zinc coated/ Upon requirement





Stainless Steel SS301/SS304 Rotary Joint Siphon Elbow For Paper Mill Dryer 0

Stainless Steel SS301/SS304 Rotary Joint Siphon Elbow For Paper Mill Dryer 1

Stainless Steel SS301/SS304 Rotary Joint Siphon Elbow For Paper Mill Dryer 2



Special siphon for high-speed dryer
Such a siphon is designed for high-speed, large-diameter cylinders designed, it has a superior siphon effect and operation of high intensity support.
